Meter Reported Error

KA-2000 may receive error messages from connected meters.

Applies to:

  • KA-2000

A Meter Reported Error will prevent a Kahler Automation system from running in automatic until the error state is cleared.

Most meters are connected with the scale ports found on the KA-2000. Scale port 1 is found on the bottom side of the KA-2000 at the far left; scale port 2 is found on the left side of the KA-2000 and may not be used. Some configurations may connect several meters via daisy-chain to one of the ports. Locate the connected meter(s) and note any status lights or error messages that indicate an error.

Mass-flow meters may cause a Meter Reported Error message due to irregular flow as a result of air in the lines or foreign objects.

If everything looks good, try power cycling the meter and note if there is any change. When power cycling equipment, always leave the device unpowered for at least 15 seconds before powering it back up.

Note: A Meter Response Error indicates a separate issue, caused by the meter not communicating to the controller.

Further Reading:

Still Need Help?

Submit an online web ticket or call us at Kahler Automation 507-235-6648 Option 2.
